S100 platform design request hardware & system explanation Type Name Description CPU main CPU Samsung S5PV210 CPU high quality Samsung CPU frequency 1GMHZ CPU main frequency ROM DDR II 512MB standard ROM hard disc INAND FLASH 4GB Can make built in map while the hard disc is 4G resolution 800*480 high resolution digital panel color 65000 color colorful display OS WINCE 6.0 Support multi-languageSupport multi-language(Russia/English/Germany/France/Italian/Spanish/Hungarian),support oversea map GPS receiver frequency: 1575.42MHZ C/A CODE protocol standard: NMEA-0183 V3.01 channel - 66 channel for searching satellite, 22 channel for tracking. tracking sense: -164 dBm locate: 3m 2D RMS BT module working frequency: 2.402 GHZ-2.480GHZ ISM Band MIC sense: -42dB touch panel 4 wires resistance ( ready adaptor for capacity panel on PCB) S100 - platform design request - function Description Main function Basic function Description system update no need special tools, update all software such as UI/MCU by sd card only. Video function Lightness/contrast/color adjustment, support style set up Dual Zone DVD TV AUX Video output, 1 chanel CVBS video output, DVD TV AUX optional Dual zone audio harness output, stereo harness output, TV AUX IPOD RADIO DVD for optional;can also select Bass for main channel output Add dual zone control adaptor Bass output Separated output iPod function Belongs to main-board,auto display when connects to IPOD device Video playing(not support currently,but there is port ready for future) Support audio playing, name display, album, singer's information DVD function Car Spec DVD loader, Build in virtual disc(20 disc) changer support DVD,DVD-R, DVD+/-RW , HDCD ,CD-R , CD+ /-RW, MP3 ,MP4 Picture CD ,VCD,WMA AUX function 2 channel, support front & rear AUX input (alternative) TV function Support analog TV, support all TV system, analog TV & digital TV - alternative DVB-T ISDB CMMB Support digital TV, DVB-T ISDB CMMB,support 2 tuners Radio Built in car spec AM/FM tuner, support RDS, support local & long-distance 99 station preset for AM, 99 station preset for FM support to scan different frequency station by area step Buletooth support built in MIC,external MIC, standard adaptor, no MIC wire support BT 2.0, A2DP, support phone book, calling record, BT music support phone book, calling recall, phone book transferred phone book language is the same as the cell phone POP 3-Zone POP GPS Built in high quality GPS module, gain satellite signal faster and stable support GPS signal query TMC GPS audio can be work together with front & rear speakers Rear camera 1 channel video input, Enter camera menu once in reverse support device on when the car in reverse External digital TV box DVB-T, CMMB, ISDB, support external digital TV box - DVB-T, CMMB, ISDB, support double digital tuner. Build in/external is alternative. External USB(2 channel, 1 A output electric current USB1: USB2.0, USB1:USB2.0, for media playing, photos reading. support WMV, AVI, MPEG, MP3, MP4, RMVB(1080P), JPEG format, support name, album, singer's name USB2- for 3G internet or WIFI input SD card SD1 - for Navigation, support SD 2.0 protocol standard SDHC, support 32GB. Support map data Support SD 2- for media playing and photo reading. Support WMV,AVI,MPEG,MP3,MP4,JPEG, support name, album,singer's name Game build in games tooling build in normal tools,calculator,calendar. GOD Support Video recording can record DVD, AUX, TV File manage build in flash and external SD, USB for data transferred
